FRAME |
DK F/S 20"; 100% 4130 chromoly: Full chromoly |
| FORK |
DK F/S Fork; 100% 4130 chromoly |
| HANDLEBAR |
DK 2-piece design; 4130 chromoly |
| STEM |
1-1/8" clamp-on w/ Gyro cable stop plate |
| HEADSET |
1-1/8" Threadless |
| GRIPS |
DK Vice Grips; Krayton |
| FRONT BRAKE |
Tektro FX-30FS linear spring U-brake |
| REAR BRAKE |
Tektro FX-30 linear spring U-brake |
| DETANGLER |
SST Oryg w/ twin lower cables |
| LEVERS |
Tektro two-finger design |
| CRANKS |
175mm tubular chromoly 3-piece design |
| CHAINWHEEL |
CNC alloy 39t DK Iron Cross |
| BB |
48-spline 19mm chromoly spindle w/ sealed bearing BB |
| PEDALS |
DK Iron Cross w/ chromoly spindles |
| CHAIN |
1/2" X 1/8" KMC Z-410; black/sliver two-tone |
| FREEWHEEL |
14t w/ 1/8" pitch |
| RIMS |
48-spoke Alex Supra Alpha single-walled alloy;
black C/P |
| HUBS |
Alloy mid flange w/ 14mm chromo axles |
| SPOKES |
Black ED plated w/ brass nipples |
| TIRES |
Maxxis Ring Worm 110 p.s.i. 1.95" multi-surface design F/R |
| SADDLE |
DK padded dirt-jumping design w/ edge protectors & Kevlar |
| SEATPOST |
25.4mm chromoly w/ micro-adjust |
| CLAMP |
Alloy single-bolt design |
| ACCESSORIES |
Four DK Peg Bundy pegs, CPSC reflector & chainguard, owner's manual
|
